    Aluminum Alloy 560mm Straight Line Wire Drawing Machine

    Ask Lasest Price
    Brand Name : OLT
    Model Number : OLT-SLWDM-02
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 10sets one month
    Delivery Time : 15days after deposit
    • Product Details
    • Company Profile

    Aluminum Alloy 560mm Straight Line Wire Drawing Machine

    Aluminum Alloy straight line wire drawing machine for low carbon wire


    1. Aluminum Alloy straight line wire drawing machine for low carbon wire description:


    High effective,high drawing speed in normal production
    Easy operation,delightful man-machine interface
    Optimized design,high reliability,low faults ratio
    High quality finish wire due to no sliding,no torsion in drawing
    Clean production environment due to install dust remove and air blowing system
    Equip with advanced motors,high efficiency and saving energy
    Low noise level compare to old type drawing machine


    2. Aluminum Alloy straight line wire drawing machine for low carbon wire parameter:


    ModelBlock Dia.(mm)Max. Draw PassesMax.Inlet Wire Dia. (mm)Min.Outlet Wire Dia. (mm)Motor Power (KW)Max.Outlet Speed(m/s)Noise Level (dBA)
    LZ-200200≤152.20.254.0-5.522≤81
    LZ-250250≤152.60.44.0-7.522≤81
    LZ-300300≤152.80.55.5-7.522≤82
    LZ-350350≤153.50.65.5-1122≤82
    LZ-400400≤154.20.7511-1522≤82
    LZ-450450≤154.50.811-2220≤82
    LZ-500500≤155.01.215-3020≤82
    LZ-560560≤155.5-6.51.322-4520≤82
    LZ-600600≤156.5-7.01.3530-5520≤82
    LZ-650650≤157.01.530-5518≤82
    LZ-700700≤158.01.845-7518≤82
    LZ-750750≤158.02.045-7516≤82

    3. Aluminum Alloy straight line wire drawing machine for low carbon wire advantage:


    PLC: Siemens
    Touch screen: Siemens
    Inverter: Yaskawa, Schneider, Siemens
    Circuit breakers and contactors: Schneider


    4. Aluminum Alloy straight line wire drawing machine for low carbon wire:


    pay-off stand----wire descaling machine (pre-treatment)----wire pointing machine----butt welding machine-----wire drawing machine----annealing machine ----spooler take-up


    5. Aluminum Alloy straight line wire drawing machine for low carbon wire character :


    It is a prefabrication equipment for the production of metal products such as standard parts. The purpose is to pull the wire or bar of the metal product manufacturing enterprise, which is produced and transported by the steel manufacturer to standard parts, through the wire drawing machine, so that the diameter of the wire or bar, The roundness, internal metallographic structure, surface finish and straightness all meet the raw material processing requirements for the production of metal parts such as standard parts.
